Aito Targeting Fire Monitor
Aito Targeting Fire Monitor automatic tracking and positioning jet fire monitor consists of mechanical components and control components. It uses ultraviolet fire sensing and infrared fire detection technology to drive the cannon mouth to rotate through the drive motor, automatically sense fire, automatically locate fire, and automatically spray water to complete the function of automatic fire extinguishing.
Key Features Aito Targeting Fire Monitors?
- Advanced Flame Detection: Uses infrared and ultraviolet technology to detect and accurately locate early fire sources, distinguishing real from false alarms.
- Reliable Design: Strong anti-interference capability for enhanced performance
- Effective Water Spray: Concentrated water jet with strong penetration, effective in extinguishing early fires.
- Wide Coverage: Ideal for large spaces with extensive protection range.
- Laser Positioning: Ensures accurate water direction with video-assisted remote confirmation.
- Emergency Stop: A button to cut off power in emergencies.
- Lightning Protection: Equipped with modules to prevent damage from lightning strikes.
Control Modes for Aito Targeting Fire Monitor
Aito targeting fire monitors utilize advanced control modes to automatically detect and suppress fires with precision. These systems provide quick, accurate responses, enhancing fire safety and minimizing risks in critical environments.
- Automatic Mode: Detects fire, activates alarms and sprays water automatically for 5 minutes, repeating if needed.
- Auto-Manual Mode: Detects fire and triggers alarms, but requires manual confirmation before water is activated.
- Manual Mode: Full manual control of detection and water spray.
Main Specification and Technical Parameters
| Automatic Tracking Fire Monitor Model | ATFM5S-RS30 | ATFM10S-RS35 |
|---|---|---|
| Product Images |  | |
| Installation Type | Hanging | |
| Maximum Protection Radius | 30m | 35m |
| Water Jet Flow Rate | 5 L/s | 10 L/s |
| Installation Height | 8 ~ 22 m | |
| Interface Diameter | DN32 | |
| Dimensions | 400 mm x 380 mm x 450 mm | |
| Product Weight | 8 kg | 9 kg |
| Rated Working Pressure | 0.6 MPa | |
| Maximum Working Pressure | 1.0 MPa | |
| Voltage/Power Consumption | AC220V/Monitor: 5W, Scan: 50W | |
| Communication Method | RS485 (Communication with Local Controller) | |
| Fire Response Time | ≤30 s | |
| Operating Temperature | 4 ~ 55 °C | |
| Horizontal Rotation Range | 0 ~ 360° | |
| Vertical Rotation Range | -90° ~ +30° | |
| Water Spray Method | Jet and then swing back and forth | |
| Matching Harness Length | 2.0 m | |
Scope Applications
Large Open Space
Industrial Buildings
Educational Instituition
Structural Description
Dimensions
System Configuration List
Aito Targeting Fire Monitor
- Aito Targeting Fire Monitor device body.
- Start detection component.
- Positioning detection components (including horizontal positioning and vertical positioning detection components).
- Addressing module, used to set RS485 communication address.
- Control module, used to collect signals, communicate with local controllers, and control device motors.
- Pencil-type waterproof camera (optional)
RS-KZ201 Local Controller
-
- Control device power supply (AC220) and solenoid valve power supply (AC220).
- Manual control of Aito Targeting Fire Monitor (ATFM) device rotation, valve start, emergency stop and other functions.
- Communicate with the automatic tracking and positioning jet fire extinguishing device via RS485 bus.
- Communicate with the control host via CAN bus.
- Output sound and light alarm.
- With LCD display, all field devices can be selected for remote linkage programming.
- Built-in black box, which can store all event records such as fire alarm, fault, action, etc.
Centralize Control Host
- Embedded digital video recorder. *Note: The recorder needs to be configured according to the actual project
- Video Hard Drive. *Note: The storage capacity of this hard is at least 1T and the capacity can also be selected according to actual requirements
- Console
- Power control panel
- 18.5-inch LCD display
- Micro LCD display
